TimberLine T0

The TimberLine T0 combines a stylish wood-accented design with excellent cooling options, including support for multiple fans and 360mm liquid coolers. It offers spacious compatibility for high-end components like ATX motherboards and large graphics cards, along with modern front I/O connectivity featuring USB Type-C. The build quality is highlighted by tempered glass panels, providing both durability and a clear view of your system.

  • Unique Aesthetic Design with Wooden Accents
  • Compatible with Back-Connect Motherboards
  • Extensive Cooling Options, including four Cosmic 12cm FRGB fans
  • Spacious Interior for High-End Components
  • Enhanced Front I/O with Modern Connectivity
  • Premium Build Quality with Tempered Glass Panels

The cooling and hardware layout shown in the product photos is for reference only.
Please check the website’s product specifications for the actual configuration.



Black
White
section-0 section-1 section-2 section-3 section-4 section-5

Specifications

  • Model TimberLine T0 BK | TimberLine T0 WH
    Case Type Mid Tower
    Color Black | White
    Front Materia ABS + woodenl
    Steel Thickness 0.7mm
    Motherboards ATX / micro ATX / mini-ITX
    Case Dimensions 453 x 235 x 450mm
    3.5” / 2.5”Drive Bays 2 / 2
    Expansion Slots 7
    GPU Clearance Supports GPU up to 410mm
    CPU Cooler Clearance Supports CPU cooler up to 181mm
    I/O Ports Type C x 1, USB3.0 x 2 , HD AUDIO
    Liquid Cooling Front & Top: support 120/240/360mm liquid cooler
    Air Cooling Rear: 1 x 120mm/140mm (Pre-Installed 1 x COSMIC 12 FR)
    Front: 3 x 120mm/140mm or 2 x 160mm (Pre-Installed 3 x COSMIC 12 FR)
    Bottom: 1 x 120mm (optional)
    Top: 3 x 120mm / 2 x 140mm (optional)
    Power Box: 2 x 120mm (optional)
